Introducing the Neo 2 Gang Vertical Switch in stylish Grey Silver, featuring LED illumination in blue. Designed for both flush and surface mounting, it offers flexibility in installation. With a 1-way switch function, it accommodates various load types, including Inductive, Resistive, Incandescent lamps, and LED bulbs, adding modern flair to any space.
Specifications
Design
| Range | Neo |
| wiring device mounting | Flush |
| Surface | Surface |
| Switch function | 1-way |
| Switch application | Switch |
| Load type | Inductive Resistive Incandescent lamp Fluorescent lamp |
| Bulb type | LED (blue) |
| Colour tint | Grey silver |
Physical
| Number of gangs | 2 gang vertical |
| Width | 87 mm |
| Height | 87 mm |
| Embedding depth | 23.5 mm |
| Depth | 36 mm |
Material
| Material | Brass: metal parts Polycarbonate: plastic part Steel: metal parts |
| Clamping connection capacity | 3 x 2.5 mm² for solid cable(s) 3 x 2.5 mm² for stranded cable(s) 4 x 1.5 mm² for solid cable(s) 4 x 1.5 mm² for stranded cable(s) |
| Connections – terminals | Pillar terminals |
| Rated current | 10 AX at 250 V AC 50/60 Hz |
