Introducing the Clipsal AvatarOn Intermediate Switch, a reliable solution for controlling various loads with ease. Designed for incandescent lamps, inductive, fluorescent lamps, and resistive loads, this switch offers versatility in application. With a rated current of 16AX at 250V AC 50/60Hz, it ensures efficient performance. The part number E8331M_WE denotes its unique identification. Simple yet effective, this switch is a practical choice for your electrical needs.
Specifications
Design
| | Product or component type | switch |
| | Switch Function | intermediate |
|
| | | Device Presentation | complete product |
|
| Device application | control |
| | Device mounting | surface, flush |
| | Standards | SS 227-1, IEC 60669-1, MS IEC 60669-1, BS EN 60669-1 |
|
| | Maximum Ambient Air Temperature for Operation | 45 °C |
| |
Physical
| | |
| Package1 Length*Width*Height | 8.6 cm x 8.6 cm x 3.0 cm |
| | | IP degree of protection | IP20 |
|
Material
| Material | polycarbonate: grid plate, polycarbonate: base, polycarbonate: dolly, polycarbonate: frame, polycarbonate + GF 20 %: actuator |
| | | Connections – Terminals | brass terminal |
|
| Clamping Connection Capacity | 3 x 2.5 mm² for solid cable(s), 3 x 2.5 mm² for stranded cable(s), 2 x 2.5 mm² for solid cable(s), 2 x 2.5 mm² for stranded cable(s) |
| | Load Type | incandescent lamp, inductive, fluorescent lamp, resistive |
| |
|
