Introducing the Neo 2 Gang Horizontal Switch in sophisticated Grey Silver, featuring a Fluorescent indicator. Designed for the Neo range, this switch supports various load types including fluorescent lamps, resistive, incandescent lamps, and inductive loads. With its 1-way switch function, it offers versatile control options. The switch can be mounted surface or flush, providing flexibility in installation. Its stylish Grey Silver color adds a touch of modern elegance to any space, while the green fluorescent bulb ensures clear visibility. Ideal for contemporary interiors seeking both functionality and style.
Specifications
Design
| Range | Neo |
| Switch Function | 1-way |
| Switch Application | Switch |
| Load Type | Fluorescent Lamp Resistive Incandescent Lamp Inductive |
| Bulb Type | Fluorescent (Green) |
| Colour Tint | Grey Silver |
Physical
| Wiring Device Mounting | Surface Flush |
| Number of Gangs | 2 gang horizontal |
| Material | Brass: Metal Parts Polycarbonate: Plastic Part Steel: Metal Parts |
| Width | 87 mm |
| Height | 87 mm |
| Embedding Depth | 23.5 mm |
| Depth | 36 mm |
Electrical
| Rated Current | 10 A at 250 V AC 50/60 Hz |
| Clamping Connection Capacity | 3 x 2.5 mm² for Solid Cable(s) 3 x 2.5 mm² for Stranded Cable(s) 4 x 1.5 mm² for Solid Cable(s) 4 x 1.5 mm² for Stranded Cable(s) |
| Connections – Terminals | Pillar Terminals |
