Introducing the Vivace 15A 3 Pin Round Switch Socket (Part Number: KB15/15N), a complete power supply solution designed for seamless integration into modern setups. With a sleek white finish and brass/phosphor bronze contacts, this switched socket ensures reliable performance. Ideal for residential or commercial use, it features on/off switching functionality and a red neon indicator for added convenience. Built with durable polycarbonate materials and featuring a flush mounting design, it offers easy installation and IP20 protection against dust and moisture. Compliant with standards SS 145, MS 589, and BS 1362-2, it guarantees safety and reliability. Perfect for indoor environments, this switched socket combines functionality with elegant design.
Specifications
Design
| Pincode Group | default |
| Part Number | KB15/15N |
| Device Short Name | KB15 |
| Device Application | Power Supply |
| Device Presentation | Complete Product |
| Main Colour Tint | White |
| Colour | White |
| Range | Vivace |
| Range of Product | Vivace |
| Switch Application | On/Off Switching |
| Outlet Poles Configuration | 2P + E |
| Pilot Light | Red Neon Indicator |
| Number of Gangs | 1 gang |
| IP Degree of Protection | IP20 |
| Terminal Identifier | Earth, L, N |
| Standards | SS 145, MS 589, BS 1362-2 |
Physical
| Width | 87 mm |
| Height | 87 mm |
| Depth | 35 mm |
| Projecting Depth | 8 mm |
| Embedding Depth | 22.0 mm |
| Device Mounting | Flush |
| Mounting Support | Wall Mounted |
| Fixing Mode | By Screw M3.5 |
| Fixing Center | 60.3 mm |
| Ambient Air Temperature for Operation | 0-40 °C |
| Ambient Air Temperature for Storage | -5-60 °C |
| Operating Altitude | ≤ 2000 m |
Material
| Material | Polycarbonate: Grid Plate, Surround, Base |
| Contacts Material | Brass and Phosphor Bronze |
| Clamping Connection Capacity | 2.5 mm² |
| Network Frequency | 50/60 Hz |
| Environmental Characteristic | Indoor Use |
| Tightening Torque | 0.4 N.m |
| Connections – Terminals | Pillar Terminal |
