Introducing the Vivace 16A 2 Pin + Earth Schuko Socket (Device short name: KB426), a complete socket-outlet solution designed for versatile power supply needs. With its sleek white finish and Schuko outlet standard, this socket ensures compatibility and reliability. Featuring a complete mechanism design, it offers easy installation and seamless integration into modern setups. Perfect for various applications, it combines functionality with elegant design.
Specifications
Design
| Product or Component Type | Socket-outlet |
| Device Short Name | KB426 |
| Device Presentation | Complete Mechanism |
| Outlet Standard | Schuko |
| Colour Tint | White |
| Outlet Poles Configuration | 2 x 2P + E with Shutters |
| Number of Gangs | 1 gang |
Physical
| Width | 86 mm |
| Height | 86 mm |
| Projecting Depth | 8 mm |
| Embedding Depth | 35 mm |
| Device Mounting | Flush |
| Mounting Support | Wall Mounted |
| Fixing Mode | By Screw M3.5 |
| Fixing Center | 60.3 mm |
Material
| Material | Polycarbonate: Grid Plate, Surround; Nylon: Base |
| Rated Current | 16 A at 250 V AC, Resistive; 16 A at 250 V AC, Inductive |
| Network Frequency | 50 Hz |
| Contacts Material | Brass and Phosphor Bronze |
| Connections – Terminals | Pillar Terminal |
| Terminal Identifier | E, N, L |
| Tightening Torque | 0.4 N.m |
| Clamping Connection Capacity | 2.5 mm² |
